The QLogic QLE2460-Fibre Channel Adapter delivers unprecedented levels of performance, scalability, and reliability. By uniquely offering intelligent networking functionality, such as intelligent interleaved direct memory access (iiDMA), RDMA, and overlapping protection domains (OPD), the QLogic 4Gb adapters ensure that the demands of the enterprise-class data center are met. For virtualization at the Fibre Channel port level, the adapters support N_Port ID virtualization (NPIV) by allowing multiple N_Port IDs to share the same physical Fibre Channel port.
QLogic is the undisputed leader in Fibre Channel Adapters with more than 15 years of experience and six generations of Fibre Channel products that have been qualified by all major server OEMs in multiple form factors. QLogic owns the most established, proven Fibre Channel stack in the industry—more than 11 million Fibre Channel ports have been shipped.
The QLogic 2400 Series Adapters deliver unprecedented levels of performance and availability as well as intelligent networking features specific to enterprise-class data centers. The adapters provide intelligent storage networking features that redefine the enterprise-class adapter, providing increased data protection, advanced frame routing, and enterprise-wide management
capabilities. Additionally, the adapters support standards-based virtualization—N_port ID virtualization (NPIV).
QLogic offers the broadest range of support for all major operating systems to ensure OS and hardware server compatibility. Drivers are available for all major operating systems and hardware server platforms. A single driver strategy per OS enables storage administrators to easily deploy and manage adapters in heterogeneous SAN configurations.
All of the company’s products meet world compliance hardware and software specifications. Each product has earned storage partner certifications and passed agency and regulatory testing. QLogic’s adapters are tested extensively with third-party hardware, along with multiple software applications, to provide best-in-class SAN interoperability and compatibility. You can be confident purchasing QLogic adapters to meet your Fibre Channel storage networking needs.
QLogic’s new, unified management application, QConvergeConsole™ (QCC), provides single-pane-of-glass management for the company’s broad product line of storage and networking adapters (Fibre Channel, converged networking, NIC, and iSCSI). In addition, QLogic supports all major APIs, giving the end user the flexibility to manage their QLogic Fibre Channel Adapter portfolio using third-party management tools.
| Physical Specifications | |||
| Ports | Single 4Gbps Fibre Channel | ||
| Form factor | Low-profile PCIe card | ||
| (6.6 in. × 2.54 in.) | |||
| Environment and Equipment Specifications | |||
| Airflow | No airflow required | ||
| Power Consumption | 5 Watts (maximum) | ||
| Operating Temperature | 0°C/32°F to 55°C/131°F | ||
| Storage Temperature | –20°C/–4°F to 70°C/158°F | ||
| Relative Humidity | 10% to 90% (non-condensing) | ||
| Storage Humidity | 5% to 95% | ||
| Cable distances | 1Gbps: 500 meters 50/125 μm fiber, 300 meters 62.5/125 μm fiber | ||
| 2Gbps: 300 meters 50/125 μm fiber, 150 meters 62.5/125 μm fiber | |||
| 4Gbps: 150 meters 50/125 μm fiber, 70 meters 62.5/125 μm fiber | |||
| Host Bus Interface Specifications | |||
| Bus interface | PCI Express | ||
| Memory | 1MB SRAM per port, 1MB flash (SPI), and 2KB NVRAM (SPI) | ||
| Hardware platforms1 | IA32 (x86), IA64, IEM64T, AMD Opteron™ 64, Sun™ SPARC®, Apple® G5 (Xserve® and Power Mac®) | ||
| Compliance | PCI Express Base Specification, revision 1.0a, PCI Express Card Electromechanical Specification, revision 1.0, PCI Bus Power Management Interface Specification, revision 1.1 | ||
| Fibre Channel Specifications | |||
| Data rate | 4/2/1Gbps auto-negotiation (4.2480/2.1240/ 1.0625Gbps) | ||
| Performance | 150,000 IOPS per port | ||
| Topology | Point-to-point (N_Port), arbitrated loop (NL_Port), and switched fabric (N_Port) | ||
| Logins | Support for F_Port and FL_Port login: 2,048 concurrent logins, and 2,048 active exchanges | ||
| Class of service | Class 2 and 3 | ||
| Protocols | FCP (SCSI-FCP), FC-TAPE (FCP-2) | ||
| Compliance | SCSI-3 Fibre Channel Protocol (SCSI-FCP), Fibre Channel Physical and Signaling Interface (FC-PH), Fibre Channel 2nd Generation (FC-PH-2), Third Generation Fibre Channel Physical and Signaling Interface (FC-PH-3), Fibre Channel-Arbitrated Loop (FC-AL-2), Fibre Channel Fabric Loop Attachment Technical Report (FC-FLA), Fibre Channel-Private Loop Direct Attach Technical Report (FC-PLDA), Fibre Channel Tape (FC-TAPE) profile, SCSI Fibre Channel Protocol-2 (FCP-2), Second Generation FC Generic Services (FC-GS-2), Third Generation FC Generic Services (FC-GS-3), Fibre Channel Framing and Signaling (FC-FS) | ||
| Tools and Utilities | |||
| Management tools | QConvergeConsole: a unified management tool (GUI and CLI) for Fibre Channel | ||
| Device utilities | Utilities for flashing bootcode | ||
| Linux® scripting tools | |||
| Boot support | BIOS, EFI, FCode | ||
| APIs | SNIA HBA API V2, SMI-S, FDMI | ||
| Operating systems | Microsoft® Windows Server®, XP Professional, Vista®; Red Hat® Linux; Novell® SLES, NetWare®; VMware® ESX™/ESXi; Oracle® Solaris®, Linux; Citrix® XenServer™; Apple Mac OS® | ||
| Agency Approvals | |||
| EMI and EMC | US: FCC Part 15, Class B | ||
| Canada: Industry Canada ICES-003, Class B | |||
| Safety | UL60950, CSA C22.2 No.60950, Class 1 Laser Product per DHHS 21CFR J | ||
| ServerHome.nl Garantie | Dit product wordt geleverd met standaard ServerHome.nl garantie |
| Product Conditie | Refurbished hardware, pre-owned, tested |
| Brand | DELL, HP, IBM, QLOGIC |
| EAN / UPC | 5704327917045 / 4333643138363 / 8338600173 / 5050689944916 / 0783386001730 |
| Model | QLE2460 |
| Part Number | PX2510401, PX2510401-22C, AE311A |
| Dell part nr. | 0PF323, 0KD414, 0DC774 |
| HP part nr. | 407620-001 |
| IBM P/N | 39R6592, 39R6526 |
| Compatible Partnummers | 0UD551 UD551 0DC774 DC774 IBM FRU 39R6526 IBM FRU 39R6525 EAN/UPC: 5704327917045 EAN/UPC: 4333643138363 EAN/UPC: 8338600173 EAN/UPC: 5050689944916 EAN/UPC: 0783386001730 |
| Full profile / Low Profile | FP |
| Card Interface | PCI-E |
| Network Poorten | 1 |
| Network Snelheid | 4G |
| Netwerk Type | FC |
| Card Interface | PCI-E |
dual Port 4G FC PCI-E Full Profile DELL, HP, IBM, QLOGIC
Model: QLE2460
Dell PN: 0PF323, 0KD414, 0DC774
HP PN: 407620-001
IBM PN: 39R6592, 39R6526
Intel PN: n/a
PN: PX2510401, PX2510401-22C, AE311A
| Weight | 1 kg |
|---|
