NOTE:

NOTE:

Configuration and color might vary depending on your model.

Product release information

Product number

2CC72AA

Release date

General

Brand:	HP
Categories:	Computers > Desktop PCs > Desktop PCs
LSN:
Barcode:
Colour:	Black • White
Model Number:	2CC72AA
Type:	PC

Operating System

Bundled Operating System:	Windows 11 (64-Bit)
Operating System Architecture:	64-bit

CPU

CPU Family:	A
CPU Speed:	3.1 GHz
CPU Type:	A8-9600
Max Turbo Speed:	4.2 GHz
Number of Cores:	Quad-Core

Memory

Discrete Graphics Memory Type:	GDDR4
Maximum Memory Supported:	16 GB
Memory Capacity:	16GB ddr4 2400
Memory Layout (slots X Size):	2 x 8 GB
Memory Slot (Total):	2x DIMM
Memory Spec:	DDR4-SDRAM
Memory Speed:	2400

Graphics

Discrete Graphics Adapter Model:	NVIDIA® GeForce® GT 730 4GB Dedicated
On-board Graphics Adapter Model:	AMD Radeon R7

Hard Drive

HDD Capacity:	1000GB
HDD Interface:	Serial ATA
HDD RPM:	7200 RPM
Number Of SSDs Installed:	1
SSD or Flash Memory Capacity:	256GB
Solid-state Drive Interfaces:	NVMe 3.0 • PCI Express
Storage Media:	HDD+SSD
Total Storage Capacity:	256GB

Optical Drive

Optical Drive Type:

DVD Super Multi

Speakers

Audio Output Channels:

5.1 channels

Integrated Devices

Card Reader:

Yes

Power

Power Supply:

300 W

Networking

Bluetooth:	Yes
Bluetooth Version:	4.2
Ethernet LAN Data Rates:	10 • 100 • 1000 Mbit/s
LAN:	Yes
WLAN:	802.11a • Wi-Fi 5 (802.11ac) • 802.11b • 802.11g • Wi-Fi 4 (802.11n)
Wi-Fi:	Yes

Ports

Combo Headphone/Mic Port:	Yes
Ethernet LAN Ports:	1
HDMI:	1
Headphone Outputs:	1
Microphone In:	Yes
USB 2.0:	2
USB 3.0 (3.1 Gen 1) Type-A Ports:	3
USB 3.0 (3.1 Gen 1) Type-C Ports:	1
VGA /D-SUB Ports Quantity:	1

Package Contents

Mouse Included:

n/a

Physical Specification

Chassis Type:	Desktop
Item Depth (mm):	315
Item Height (mm):	307
Item Width (mm):	163
Weight (kg):	5.7

Certifications

EPEAT Compliance:

Silver

• Microsoft Windows 11 (64-bit)/Office2007/vlc player/adobe reader. very good condition

HP Pavilion 570-p048a Desktop PC Product Specifications

NOTE:

Configuration and color might vary depending on your model.

Product release information

Product number

2CC72AA

Country/Region sold in

Australia/New Zealand

Motherboard

Willow2

Figure : Willow2 motherboard top view

• Form factor: Customized: 22.0×20.5 cm (8.7×8.1 in)
• Chipset: AMD Promontory FCH
• Memory sockets: 2 x DDR4
• Processor socket: AM4
• Expansion Slots:
  • One PCI-E x16 socket
  • One M.2 socket 1, key A
  • One M.2 socket 3, key M
• For more details, see Willow2 motherboard specifications.

Video graphics

NVIDIA GeForce GT 730 (4 GB)

Figure : Video card

Figure : Video card ports

1. HDMI
2. DVI-I

• Form factor: Low profile PCB with ATX
• Dimensions: 6.9×14.5 cm (2.7×5.7 in)
• Rear I/O connectors: Dual Link DVI-I + HDMI
• Maximum resolution:
  • HDMI resolution: 1920 x 1080 @ 60 Hz (HDMI 1.4)
  • DVI resolution: 2560 x 1600 x 32bpp @ 60Hz (Dual Link)
  • Analog VGA (via DVI to VGA adapter – not included with card) resolution: 2048 x 1536 x 32bpp @ 60Hz

    NOTE:

    This card does not have a VGA connector. VGA connection is only possible through a DVI to VGA adapter which is not inclued with the graphics card.

• Memory size: 4 GB (64-bit)
• Memory type: 256M x 16 DDR3 (Micron/Hynix) @ 8pcs
• Supports Blu-ray
• Total power consumption: <35 W max
• Supports up to 2 displays at the same time
• Engine clock: 901 MHz
• Memory clock: 900 MHz
• Cooling: Active fan-sink (Active cooling with dynamic speed)
• External power cable: No
• Internal ports: 2-pin fan connector for fan sink power

Integrated graphics

• Integrated AMD Radeon R7 Graphics

  NOTE:

  Integrated video is not available if a graphics card is installed.

Sound/Audio

Integrated audio

• Audio Codec: ALC3863-CG
• High Definition (Azalia) 5.1 channel audio support

  NOTE:

  The motherboard supports 5.1 surround sound. If the computer does not have the required audio jacks for a 5.1 configuration, additional hardware is required to use 5.1 surround sound.

• Audio jack presence detection

  NOTE:

  An internal speaker is not included with integrated audio. External speakers or headphones are required to hear sound.

  NOTE:

  Integrated audio is not available if a sound card is installed.

Networking

Wireless LAN 802.11a/b/g/n/ac (1×1) and Bluetooth 4.2 M.2

• Interface: M.2
• Transmission standards: 802.11 a/b/g/n/ac

LAN: 1000BASE-T

• Technology: Realtek RTL8161
• Data transfer speeds: up to 10/100/1000 Mb/s
• Transmission standards: 1000BASE-T Ethernet

Hard drive

256 GB PCIe NVMe TLC M.2 Solid State

• Size: 256 GB
• Interface: M.2
• Type: TLC Solid State

1 TB

• Size: 1 TB
• Interface: SATA
• Rotational Speed: 7200 RPM

CD/DVD disc drive

DVD Writer

• Data transfer rates up to 3,600 KB/s (CD read/write)
• Data transfer rates up to 10,800 KB/s (DVD read/write)

Formats/Disc types	Write speeds	Read speeds
DVD
DVD-ROM SL	N/A	up to 8x
DVD-ROM DL	N/A	up to 8x
DVD+R SL	up to 8x	up to 8x
DVD+R DL	up to 6x	up to 8x
DVD-R SL	up to 8x	up to 8x
DVD-R DL	up to 6x	up to 8x
DVD+RW	up to 8x	up to 8x
DVD-RW	up to 6x	up to 8x
CD
CD-R	up to 24x	up to 24x
CD-RW	up to 10x	up to 24x
CD-ROM	N/A	up to 24x

Memory card reader

3-in-1 memory card reader

Figure : Memory card reader

Supports the following cards:

• Secure Digital (SD)
• Secure Digital High Capacity (SDHC)
• SDXC

Computer case

Chassis

• Height: 30.71 cm (12.09 in)
• Width: 16.31 cm (6.42 in)
• Depth: 39.50 cm (12.40 in)
• Weight 5.70 kg (12.57 lb) – without packaging

Power supply

Internal 300 W power supply

• 300 W internal E6 Bronze efficiency power supply
• Active efficiency Bronze level: 85%

I/O ports

Front I/O ports

• USB 3.0: 1
• USB 3.0-Type C: 1
• Headphone/Microphone: 1

Back I/O ports

NOTE:

The configuration might vary depending on your model (for example, if a dedicated graphics card is included). Any modifications or upgrades might change the configuration, port accessibility, and port functionality.

Figure : Willow2 back I/O panel

1. VGA
2. HDMI out
3. USB 3.0: 2
4. USB 2.0: 2
5. LAN (Ethernet)
6. Audio jacks
